IBDRW100-EX-Winmate Bay Trail Slim DIN Rail PC Embedded Automation Controller
Features
Ľ Design for Industrial Automation, Din Rail application
Ľ Onboard Intel Celeron Quad-Core N2930 1.83GHz
Ľ 1 x DDR3L SODIMM slot, max. 8GB
Ľ 1 x RS232 / 422 / 485 communication, switch by jump (Default:RS232)
Ľ 4 x Giga LAN, 1 x USB 3.0, 3 x USB 2.0, 1 x VGA,
1 x Line out, 1 x Power Jack
Ľ Fanless ,High effciency thermal design
Ľ ATEX & C1D2 Certification *
Ľ AWS loT Greengrass Certified
System Specification
| Processor | Intel® Celeron® Bay Trail-M N2930 1.83GHz |
| System Chipset | Bay Trail SoC Chipset |
| System Memory | 1 x DDR3L 1333MHz SO-DIMM, Default 4GB, Max. up to 8GB |
| Ethernet Controller | 4 x Intel® I210 GbE LAN |
| USB | 1 x USB 3.0, 3 x USB 2.0 (external) 2 x USB 2.0 by pin-header (internal) |
I/O Connectors
| Front Side I/O |
|
Mechanical and Environment
| Dimensions (L x W) | 139mm x 65mm x 152mm(L x W x H) |
| Color | Dark Silver |
| Construction | Metal housing |
| Power Input | 9~36V DC IN (Isolation) |
Mechanical & Environment Specification
| Operating Temperature | -20 to 60 deg.C |
| Operating Humidity | 5% to 95% (non condensing) |
| Certifications |
Class I, Division 2, Groups A, B, C, D; T4 Max. 60oC ATEX II 3 G Ex nA IIC T4 Gc Max. 60oC |
| Mounting | Desktop / Wall-Mounting |
| Power consumption | 25W |
Product Spec
| Storage | Default 64GB mSATA SSD Optional : 64GB to 512GB 2.5″ SSD |
| OS |
|
