The elegantly designed, yet rugged, industrial grade G-WIN GC series is designed for tractors, agricultural and other heavy duty vehicles. With rugged construction, ultimate computing power, GC series are guaranteed to meet „heavy duty“ needs. This series feature high computing power and user-friendly interface with projected capacitive multi-touch (P-CAP) technology.
Features:
- 23.8″ 1920 x 1080 PCAP touchscreen
- Intel® Pentium® N4200 Apollo Lake Processor
- Fanless cooling system and ultra low power consumption
- Front IP65 water and dust proof
- A true flat, easy-to-clean front surface with edge-to-edge design
LCD Panel Specification
| Size | 23.8” TFT |
| Resolution | 1920 x 1080 |
| Contrast Ratio | 3000 : 1 (typ.) |
| Panel Brightness | 250 cd/m (typ.) |
| Viewing Angle | -89~89(H);-89~89(V) |
| Touch Screen | Projected Capacitive Multi-Touch |
| Maximum Colors | 16.7M |
System Specification
| Processor | Intel® Pentium® N4200 (2M Cache, up to 2.5 GHz) |
| Memory | 2GB DDR3L 1866 SO-DIMM (Optional 8 GB) |
| Storage | 64GB M.2 SSD (Default) |
| OS Support | Windows 10 IoT Enterprise |
| LAN | Dual Intel® I210-AT GbE LAN |
I/O Connectors
| Serial | 1 x RS-232/422/485 |
| USB Port | 2 x USB 3.0 |
| Ethernet | 1 x RJ-45-10/100/1000 Mbps, 1 x RJ-45 |
Mechanical and Environment
| Operating Temperature | 0 °C to 50 °C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Mounting | VESA Mount (100x100mm) |
| Dimension (W x H x D) | 588 x 358 x 55 mm |
| IP Proof | Front IP65 |
Product Spec
| Security Support | Trusted Platform Module (TPM 2.0) |
Power
| Power Input | 12V DC in |
| Power Consumption | 29 W |
