The MIC-1816 is a standalone automation controller with integrated data acquisition module and signal conditioning to provide digital I/O, analog I/O and counter functions. This controller also supports serial communication ports and several other networking interfaces. You can seamlessly integrate your applications into the MIC-1816 series and speed up your system development with these application ready controllers.
16 analog inputs, up to 1 MS/s, 16-bit resolution
2 analog outputs, up to 3 MS/s, 16-bit resolution
Support for digital trigger and analog trigger
16 x isolated digital input and 8 x isolated digital output
Two 32-bit programmable counter/timers
Onboard FIFO memory (4,096 samples)
2 x RS-232 ports
2 x 10/100/1000 Base-T RJ-45 LAN ports
2 x USB 2.0 and 2 x USB 3.0 ports
iDoor expansion supported
